Accessories
AHP-WU.2
-
![STIEBEL ELTRON Accessories AHP-WU.2]()
Questions about the product Get contact- Wall outlet for easy installation of the connection lines of an air source heat pump with R290 refrigerant
- Suitable for new build and modernisation projects
- Can be combined with KG/HT pipe DN200
- For embedding in waterproof concrete or in pipe liners set in concrete
- Water pressure-tight up to 3 bar
![STIEBEL ELTRON Accessories AHP-WU.2]()
Product details
Description • Wall outlet for underground supply and return pipes for heat pumps installed outdoors with concrete walls ("white tank") or pipe liners set in concrete. Also with two empty conduits for the power supply. • With sealing insert for combination with KG/HT pipe DN200. Suitable for core holes or pipe liners with an inner diameter of 250 mm. • Easy installation thanks to torque control via the nuts. Closure of the annular space between the KG/HT pipe and bore/pipe liner. • Water pressure-tight up to 3 bar.
Installation Information:
Please ask your local power supply utility or a registered electrician to install appliances that are not fully wired, i.e. ready to plug in. The electrician should also be able to assist you with obtaining the agreement of the respective power supply utility required for the appliance installation.
