Wall mounted cylinder
SHD 100 S

    • Hydraulically controlled wall mounted cylinder
    • Simple temperature selection from 35-85 °C with variable adjustment on the appliance
    • High connected load for quick DHW heating
    • Rapid heat-up button for demand-dependent heating
    • Special enamel coating for a long service life
    Questions about the product Get contact

    Product details

    Enjoy the benefits of DHW reliability

    With this appliance, we are offering you a virtually limitless supply of hot water. This is possible, because we have combined the advantages of an instantaneous water heater and a cylinder. High output meets clever cylinder technology. Do you ever need hot water in a hurry? Not a problem: simply press the rapid heat-up button and the stored hot water is heated in no time. For complete everyday flexibility.


    ERP product datasheet
    Reach-Information
    Technical datasheet

    Product Number: 073060

    Connected load ~ 400 V: 3,4/20,4 kW

    Power supply: 3/PE

    Rated voltage: 400 V

    Frequency: 50 Hz

    Load profile: L

    Energy efficiency class: C

    Standby energy consumption/24 h at 65 °C: 0.86 kWh

    Nominal capacity: 100 l

    Mixed water amount at 40 °C: 133 l

    Temperature setting range: 35-85 °C

    Max. flow rate: 18 l/min

    Height: 1050 mm

    Width: 510 mm

    Depth: 510 mm

    Show all

    Download as PDF

    Equipment datasheet

Installation Information:

Please ask your local power supply utility or a registered electrician to install appliances that are not fully wired, i.e. ready to plug in. The electrician should also be able to assist you with obtaining the agreement of the respective power supply utility required for the appliance installation.
