Comfort instantaneous water heaters
HDB-E 18/21/24 Trend

  • Product details

    Enjoy pleasantly warm water

    This model reliably supplies one or more draw-off points in your home with a stable DHW temperature. We have set the highest possible temperature for you at the factory. Two sensors in the appliance calculate the output needed to achieve the required outlet temperature. Only the amount of energy actually required is expended. This makes your DHW use efficient and saves you money.



    Perfectly adjust your preferred temperature

    Is the outlet temperature too high for you? No problem – your qualified contractor will set it directly on the appliance to one of the four possible DHW temperatures. The individual preferred temperature is achieved directly at the tap by mixing in cold water. You will benefit completely from it when washing your hands or washing up.



    ERP product datasheet
    Reach-Information
    Technical datasheet

    Product Number: 204209

    Rated voltage: 400 V

    Rated voltage 1: 380 V

    Rated voltage 2: 400 V

    Rated output: 18/21/24 kW

    Rated output 1: 16,2/19/21,7 kW

    Rated output 2: 18/21/24 kW

    Rated current: 29/31/35 A

    Rated current 1: 27,6/29,5/33,3 A

    Rated current 2: 29/31/35 A

    Fuse protection: 32/32/35 A

    Fuse protection 1: 32/32/35 A

    Fuse protection 2: 32/32/35 A

    Frequency: 50/60 Hz

    Frequency 1: 50/60 Hz

    Frequency 2: 50/60 Hz

    Phases: 3/PE

    IP rating: IP 25

    Temperature setting: 35, 43, 50, 55 (400V) °C

    Colour: white

    Height: 466 mm

    Width: 225 mm

    Depth: 105 mm

    Weight: 2.90 kg

    Energy efficiency class: A
